Rice Harvester Chains

Rice Harvester Chain

Rice harvester chains are essential components in rice harvesting machinery, specifically designed to handle the demanding conditions of rice fields, including wet and muddy environments. These chains play a crucial role in cutting and conveying rice plants efficiently, ensuring a smooth harvesting process.

✔ Durability & Strength

✔ Corrosion Resistance

✔ High Load-Bearing Capacity

✔ Precision Engineering

Rice Harvester Chain Size

415 Series Hoisting Chains Rice Harvester Chains

415 Series Hoisting Chains Rice Harvester Chains Dimension Chart

CTS® Chain No.	Pitch	Roller diameter	Width between inner plates	Pin diameter	Pin length			Inner plate depth	Plate thickness	Attachment dimension		Tensile strength	Average tensile strength
	P	d1 max	b1 min	d2 max	L max	Lc max	Ld max	h2 max	T max	d3 nom	C	Q min	Q0
	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf	kN
415F1	12.7	7.77	4.90	3.64	11.0	12.1	12.95	9.5	1.1	4.02	12.0	6.86/1559	8.1
415F2	12.7	7.77	4.90	3.64	11.0	12.1	12.95	9.5	1.1	4.02	12.0	6.86/1559	8.1
415F3	12.7	7.77	4.90	3.64	11.0	12.1	12.95	9.5	1.1	4.02	12.0	6.86/1559	8.1
415F4	12.7	7.77	4.68	3.62	11.8	-	-	9.6	1.3	4.00	12.0	10.30/2341	12.1
415F5	12.7	7.77	4.68	3.63	11.8	13.0	14.00	9.6	1.3	4.00	12.0	10.30/2341	12.1
415S	12.7	7.77	4.80	3.96	12.8	14.3	15.70	12.0	1.5	4.02	12.0	15.69/3566	16.3
415S-A	12.7	7.77	4.90	3.96	12.8	14.3	15.70	12.0	1.5	4.02	12.0	13.80/3136	16.3
415SF1	12.7	7.77	4.80	3.96	13.0	14.5	-	10.4	1.5	4.50	12.0	13.93/3166	16.3
415SF4	12.7	7.77	4.80	3.96	13.0	14.5	15.70	12.0	1.5	4.00	12.0	13.80/3136	16.3
415SF6	12.7	7.77	4.80	3.96	13.0	14.5	15.70	10.4	1.5	4.00	12.0	13.93/3166	16.3
415SF7	12.7	7.77	4.80	4.00	13.0	14.5	15.70	12.0	1.5	4.50	12.0	15.69/3566	16.3
415SF10	12.7	7.77	4.80	4.00	13.0	14.5		12.0	1.5	4.50	12.0	13.93/3166	16.3
415SF16	12.7	7.77	4.80	3.60	11.0	12.1	13.00	12.0	1.1	4.00	12.0	6.86/1559	8.1
420JF1	12.7	7.77	6.25	3.96	14.7	16.1	18.50	12.0	1.5	4.00	12.0	16.00/3636	18.8

CTS® Chain No.	Pitch	Roller diameter	Width Between inner plates	Pin diameter	Pin lengthen		Tooth angle	Plate dimensions		Ultimate tensile strength	Type
	P	d1	b1	d2	L	Lc	α	h	H	Q
	P	max	min	max	max	max	α	h	H	min
	mm	mm	mm	mm	mm	mm	Angle	mm	mm	mm
3318T	33	10.1	18	7.0	29.5	32.0	70°	13	38	19.6	Ⅰ
3322T	33	10.1	22	7.0	33.5	36.0	70°	13	38	19.6	Ⅰ
3325T	33	10.1	25	7.0	36.5	39.0	70°	13	38	19.6	Ⅰ
3325Ta	33	10.1	25	7.0	35.2	37.4	90°	13	38	19.6	Ⅰ

3330T1	33	10.1	30	7.0	41.5	44.0	60°	13	43	19.6	Ⅰ
3330T2	33	10.1	30	7.0	41.5	44.0	70°	13	38	19.6	Ⅰ

3330Ta	33	12.8	30	7.0	39.5	42.5	70°	13	38	19.6	Ⅰ
3358T	33	10.1	58	7.0	69.5	72.0	70°	10	43	19.6

3358Ta	33	10.1	58	7.0	68.5	70.8	75°	10	43	19.6	Ⅰ
3358T	33	10.1	58	7.0	69.35	71.7	90°	15	48	22.5	Ⅰ
3358b	33	12.8	58	9.5	70.1	72.8	α：90°	13	H1：38	19.6	Ⅱ
3358b	33	12.8	58	9.5	70.1	72.8	β：75°	13	H2：46	19.6	Ⅱ
3358C/C"b	33	12.7	58	9.5	70.3	72.9	α：90°	13	H1：38	19.6	Ⅱ
3358C/C"b	33	12.7	58	9.5	70.3	72.9	β：70°	13	H2：46	19.6	Ⅱ

CTS® Chain No.	Pitch	Roller diameter	Width Between inner plates	Pin diameter	Pin lengthen		Tooth angle	Plate dimensions		Ultimate tensile strength	Type
	P	d1	b1	d2	L	Lc	α	h	H	Q
	P	max	min	max	max	max	α	h	H	min
	mm	mm	mm	mm	mm	mm	Angle	mm	mm	mm
3330	33	12.7	30	5.94	43.5	45.6	60°	h1:13	H1：43	19.6	Ⅱ
3330	33	12.7	30	5.94	43.5	45.6	60°	h2:15	H2：45	19.6	Ⅱ
3330a	33	12.7	30	5.94	43.5	45.6	70°	13	38	19.6	Ⅰ
3322	33	12.7	22	5.94	35.5	37.6	70°	15	40	19.6	Ⅰ
3358	33	12.7	58	7.0	70.9	73.5	α：90°	13	H1：38	19.6	Ⅱ
3358	33	12.7	58	7.0	70.9	73.5	β：75°	13	H2：46	19.6	Ⅱ
